3ZB127 Water Injection Pump

3ZB127 Water Injection Pump for oilfield applications: 20 m³/h at 40 MPa, up to 373 spm, 132 kW. Robust 30–57 mm plungers, suitable for ≤80°C media.

Weifang Shengli Petrochemical Machinery Co,Ltd

Tel : +86-536-8573288

Mobile(WhatsApp): +86 18353679682

Email:qzx@cnshengli.cn

◉ PRODUCT SPECIFICATION

3ZB127 Technical Parameters
Input Medium	Oilfield Sewage
Medium Temperature(℃)	≤80
Suction Pressure(Mpa)	0.03-0.3
Pressure Rating(Mpa)	40
Rated Flow(m³/h)	20
Stroke(in)	127
Plunger Diameter(mm)	30-57
Rated Pump Speed(spm)	≤373
Rated Power(KW)	132
Rod Load(KN)	42
Total Weight(Kg)	3500
Overali Dimension(mm)	3530×1930×1660

3ZB127 Water Injection Pump Specification Sheet.pdf
